Mantaro Precious Metals strategically positioned to unlock value from high-grade deposits in Latin America – Richard Mills

2023.04.01

Mantaro Precious Metals strategically positioned to unlock value from high-grade deposits in Latin America

Given what has transpired in 2023, it seems as though all the ingredients are in place for another multi-year bull cycle for gold.

In previous bull cycles, junior gold mining stocks have outperformed the physical metal. Therefore, investing in prospective gold and silver producers seems like an attractive proposition.

While there are lots of gold-silver explorers scattered across the world’s leading nations, those focused on emerging markets with proven production offer the promise of a much higher reward, given a lot of these regions remain underexplored to this day.

One such company is Mantaro Precious Metals (TSXV: MNTR) (OTCQB: MSLVF) (FSE: 9TZ), a Canadian junior that has strategically positioned itself in two Latin American nations that have historically been among the top producers of gold and silver.

In Peru, the company currently has a 100% interest in the Santas Gloria silver property, while in Bolivia it has the option to acquire up to an 80% interest in the Golden Hill orogenic gold property.

1. Santas Gloria Property

Located 55 kilometres directly to the east of Lima, the Santas Gloria project comprises 3 concessions covering 1,100 hectares. Silver is the main target commodity, along with zinc and lead.

Mineralization at Santas Gloria is of an intermediate sulphidation epithermal type — as is typical of many of the underground mines in the area such as Austria Duvaz, Argentum, Yauliyacu and Casapalca (see map below).

Globally such deposit types are attractive exploration targets due to their high-grade nature and the large vertical extent of precious and base metal endowment.

Part of Santas Gloria’s exploration appeal is that the property has only been subject to small-scale mining in the past, and the mineralization has never been drill tested.

To date, a total of 16 veins and major vein splays have been defined with a cumulative strike extension of at least 12 kilometres. About 2 km of underground workings have exploited just two small areas of San Jorge and Tembladera veins, allowing Mantaro to conduct underground channel sampling of part of the veins.

Underground channel sampling of accessible historical workings by the company returned silver grades of up to 10,000 g/t, lead grades of up to 5% and zinc grades of up to 2.5%. A total of 111 channel samples were taken over a cumulative strike length of several hundred metres, 16 of which assayed above 1,000 g/t silver.

According to Mantaro, these channel samples were from parts of veins that were not the focus of historical mining. As such, the results are likely to be of a lower tenor than the material that was mined, which means grades could go even higher with further exploration.

At surface, Mantaro has channel sampled approximately 30% of known vein outcrops; all veins are pervasively oxidized at surface and leached of all sulphides. Despite the leaching, surface channel sampling has defined robust silver and gold grades along six veins, including a coherent and strong gold anomaly (up to 56 g/) over a strike length of approximately 200 metres.

Because Santas Gloria is a silver-base metal vein system, otherwise known as Cordilleran silver-base metal type, the exploration target is likely to be characterized by high grades with excellent depth.

Evidently, the veins at Santas Gloria are steeply dipping, up to 4 metres wide, and display multiphase and brecciated texture. Multiple fluid pulses and open space created during brecciation are critical in the development of high-grade mineralization.

Metal deposition is by non-boiling precipitation, which results in deposition of metals over large vertical intervals. Localized boiling at the tops of the system may result in high-grade bonanza shoots, which may explain the high surface gold grades.

2. Golden Hill Property

Mantaro’s second project, the Golden Hill property, is situated in the underexplored Precambrian Shield of Bolivia. It is a fully permitted project located on a crustal scale structure which hosts at least six other significant gold occurrences and deposits.

The mineralization at Golden Hill is of greenstone-hosted orogenic gold type. Gold is contained within 1-5m wide sub-vertically dipping quartz shear zones, typically found along faults at the contacts between mafic volcanic and metasedimentary units of pre-Cambrian age.

According to Mantaro, these deposit types have the potential for kilometres of strike extension and kilometre-depth potential.

The vein system has so far been traced for over 4 km on the property, located in the hanging wall of a regional controlling fault to the west. This style of mineralization can be observed across the region and notably 2 km to the north of the property at the Puquio Norte gold mine, which produced over 350,000 oz between 1997 and 2003.

From a regional perspective and comparison with other greenstone belts worldwide, Golden Hill is, without a doubt, an attractive project.

The Bolivian Pre-Cambrian shield is larger than the famous Abitibi greenstone belt in Canada, yet the Bolivian shield has produced less than 10 million oz compared to 170+ million oz in the Abitibi from over 100 mines since 1901.

Similarly, the gold endowment of the West African shield, the greenstone belts of northeast South America (Venezuela, Guyana, Suriname and Brazil) and the Yilgarn province of Western Australia were much greater than equivalent areas of the Bolivian shield, as the latter remains largely underexplored to this day.

As with other greenstone belts and mineralized provinces worldwide, mineralization in the Bolivian shield is hosted along major crustal structures which juxtapose different lithologies against each.

Regional-scale structures serve to focus mineralizing fluids, whilst rocks of different competency, provide a regime for both ductile and brittle deformation and thus creation of space for deposition of quartz, pyrite and gold.

Mafic volcanics are especially favourable hosts due to the high iron content which reacts with sulphur in mineralizing fluids to form pyrite — causing gold to precipitate from the mineralizing fluids.

As for Golden Hill, the mining concession is centered on a broadly north-south trending regional structure that hosts the La Escarcha underground mine and Gabby, the Garrapatillia and Brownfields workings, and gold-bearing vein occurrences in its western hanging wall.

The same structure hosts numerous saprolite gold and hard rock gold deposits to the north and south of the Golden Hill concession over a strike length of at least 25 kilometres, underpinning the significant control the structure exerts on gold mineralization.

Prior to Mantaro entering the project in 2021, one of the main quartz veins at La Escarcha was being mined at a rate of up to 25 tonnes per day to a depth of 60 metres. The mine permit at Golden Hill allows for production to be increased subject to the company completing its own economic studies on the project and sufficiently funding any upgrades.

“Golden Hill is an advanced-stage project with significant exploration upside. A drill-ready orogenic gold project in Bolivia is an excellent complement to our existing high-grade silver assets in Peru,” chief geologist Chris Wilson said at the time of signing the option agreement.

To date, four major gold mineralized zones (La Escarcha, Gabby, Garrapittilia and Brownfields) have been identified across the 4 km strike length. Historical drilling on the property was only limited to the La Escarcha pit area.

In 2022, Mantaro completed 21 diamond core drill holes at Golden Hill for over 3,000 metres of drilling. The best assays include 5 m at 7.57 g/t gold from 87 m downhole; 3.4 m at 8.27 g/t gold from 67.6 m downhole; and 14.0 m at 3.57 g/t gold from 105 m downhole.

Following this initial drill program, Mantaro will now work to understand the controls on the high-grade zones within the mineralization, as well as conduct preliminary modelling with a view to targeting a resource estimate.

Exploration Plans

To support its continued exploration efforts, Mantaro recently closed a private placement for total proceeds of $365,370. This financing was slightly oversubscribed, and had the backing of company insiders.

A large portion of funds will be used to advance its Santas Gloria property in Peru, for which drilling authorization was obtained in November. Drilling will initially target four high-grade silver and/or gold vein systems.

According to Mantaro, the Santas Gloria property is the “ideal project” to carry out its next phase of drilling activities due to the extensive silver and gold-rich system. “Numerous high-grade silver and gold intermediate sulphidation epithermal veins run through Santas Gloria at surface and present excellent targets,” it says.

In order to optimize its drill targeting, Mantaro has already carried out preliminary metallurgical testwork on the project that demonstrated robust gold and silver recoveries above 80% — a sign of what’s to come.

In Bolivia, the Golden Hill property, with its high grades and the forthcoming resource estimate, is also one to watch. Shortly after the 2022 drilling had started, Mantaro acted quickly to exercise its option for a 51% majority interest, showing the degree of confidence it has in the project.

Mantaro Precious Metals Corp.
TSXV: MNTR, OTCQB: MSLVF, FSE: 9TZ
Cdn$0.04, 2023.03.29
Shares Outstanding 69.8m
Market cap Cdn$2.8m
MNTR website

Richard (Rick) Mills
aheadoftheherd.com
subscribe to my free newsletter
